Engineered to respect privacy
MotionCam is designed to control your security, not your personal life. The motion detector is unable to take pictures by request. The camera activates only in response to a motion alarm. The data is encrypted throughout the processes of transmission and storage. No one analyzes it, even the AI. You won’t need to live under the constant supervision of the security cameras to know why the alarm went off.
Photo capture only when triggered
All pictures are encrypted
We don’t see your photos
Photo capture only when triggered
All pictures are encrypted
We don’t see your photos
Dispels any suspicions
MotionCam ignores pets (up to 50 cm in height) using the SmartDetect algorithm. But if an especially curious pet manages to set off the alarm, the following photo report will confirm that the house is safe.
Tech specs
| Classification | Electro-optical combined radio channel security detector with a photo camera |
|---|---|
| Detector type | Wireless |
| Installation | Indoors |
| Motion detection distance | Up to 12 m |
| Pet immunity | Weight: up to 20 kg Height: up to 50 cm |
| Compatibility | Only with Hub 2, Hub 2 Plus |
| Sensing element | PIR sensor |
| Detection angles | Horizontal — 88.5° Vertical — 80° |
| MotionCam detectors support | + |
| Time for motion detection | From 0.3 to 2 m/s |
| Camera view angle | 90° |
| Photo verification | Time to deliver a photograph with default settings: up to 9 sec Photo quality: up to 640 × 480 Pictures in a series: 1-5 pcs |
| IR backlight for night mode pictures | Available |
| Sensitivity | Adjustable, 3 levels |
| Recommended installation height | 2.4 m |
| Power supply | Batteries: CR123A (×2), 3 V |
| Battery life | Up to 4 years (up to 2.5 years if “Delay when entering” setting is activated) |
| Jeweller radio technology | CCommunication range with detectors: up to 1,700 m in the line of sight Two-way communication between devices Operating frequencies: 866.0 – 866.6 MHz Self-adjusting RF output power: up to 20 mW Block encryption based on AES algorithm Detector polling period: 12−300 s Frequency hopping |
| Wings radio technology | Transmission of visual alarm verifications |
| Operating temperature range | From 0°C to +40°C (manufacture date up to June 1, 2020) From -10°C to +40°C (manufacture date from June 1, 2020) |
| Operating humidity | Up to 75% |
| Anti-sabotage | Fraud protection Jamming notification Tamper-resistant |
| CMS compatibility | Motion alarms are transmitted to CMSs that support SIA and Contact ID protocols Visual alarm verifications are transmitted to the Manitou, ABsistemDC(NG), SBN, WBB, V1/F1, Kronos, Sentinel, eLipse, Horus Central Monitoring Stations and Ajax PRO Desktop app |
| Remote configuration and testing | + |
| Protection class | IP50 |
| Dimensions | 135 × 70 × 60 mm |
| Weight | 167 g |
| Warranty | Replacement and repair for a period of 24 months from the date of sale. The warranty does not cover batteries. |
| Complete set | MotionCam motion detector SmartBracket mounting panel x2 CR123A batteries (pre-installed) Installation kit Quick Start Guide |
