Features Flexibility at the core
Settings versatility and low power consumption make Relay a universal tool for equipment control. Dry contact is not galvanically connected to the device power supply so that it can be used both in low-voltage and household networks. There are bistable and pulse modes. The relay can be easily connected to a power supply unit paired with a backup battery.
Pulse 0.5–255 seconds
Power supply 7–24 V DC
Dry contact
Pulse 0.5–255 seconds
Power supply 7–24 V DC
Dry contact
Tech specs
| Classification | Radio channel relay unit |
|---|---|
| Device type | Wireless |
| Installation method | Into electric switchboard, junction box |
| Compatibility | Operates with all Ajax hubs, and range extenders |
| Actuating element | Electromagnetic relay |
| Relay service life | 200,000 switch-ons |
| Voltage protection | Max — 36.5 V, min — 6.5 V |
| Maximum load current | 5A at 36V DC, 13A at 230V AC |
| Maximum current protection | No |
| Maximum temperature protection | >65°C in the wall plate |
| Electric power meter function | No |
| Energy consumption parameter check | Voltage |
| Power supply | 7 – 24 V (DC only) |
| Operation modes | Impulse Bistable |
| Contact state | Normally open Normally closed |
| Adjustable pulse duration | 0.5–255 sec |
| Jeweller radio technology | Communication range with central unit — up to 1,000 m in an open space Two-way communication between devices Operating frequencies — 866.0 – 866.6 MHz Self-adjusting RF output power — up to 25 mW Block encryption based on AES algorithm Device scanning period — 12 – 300 s |
| Operating temperature range | From 0°С to +64°С |
| Permissible humidity | Up to 75% |
| Anti-sabotage | Protection against fraud Jamming detection |
| Protection class of body | IP20 |
| Remote setting and testing | + |
| Dimensions | 39 × 33 × 18 mm |
| Weight | 25 g |
| Warranty | Replacement and repair within 24 months of the date of sale. |
| Complete set | Relay Installation set User’s guide |
