Everything is ready for you by the time you get home
You will come back home to enjoy comfortable climate and cozy atmosphere all year round. Turn on your heating devices during winter and air conditioner during summer. Start your air humidifier and heat water for your bath. With only a few taps in the application on your way home.
Tech specs
| Classification | Radio channel relay unit |
|---|---|
| Device type | Wireless |
| Installation method | In power outlet |
| Compatibility | Operates with all Ajax hubs, and range extenders |
| Actuating element | Electromagnetic relay |
| Voltage and type of external power supply | 110 – 230 V, 50/60 Hz |
| Voltage protection for 230 V mains | Yes, 184 – 253 V |
| Relay service life | 200,000 switch-ons |
| Voltage protection | Max — 36.5 V, min — 6.5 V |
| Maximum load current | 11 A (continuous), 13 A (up to 5 s) |
| Maximum current protection | Yes, 11 A if the protection is turned on, up to 13 A if the protection is turned off |
| Maximum temperature protection | Yes, +85°С. The socket turns off automatically if the temperature is exceeded |
| Electric shock protection class | Class I (with grounding terminal) |
| Electric power meter feature | Available |
| Energy consumption parameter check | Current, voltage, power consumption |
| Alarm signal delivery time | 0.15 s |
| Load indicator | Available |
| Output power (resistive load at 230 V) | Up to 2.5 kW |
| Average energy consumption of the device on standby | Less than 1 W |
| Operation modes | Impulse (firmware version 5.54.1.0 or higher. Manufacture date from March 4, 2020) Bistable |
| Contact state (firmware version 5.54.1.0 or higher) | Normally open Normally closed |
| LED indication | Adjustable |
| Adjustable pulse duration (firmware version 5.54.1.0 or higher) | 0.5–255 sec |
| Jeweller radio technology | Communication range with central unit — up to 1,000 m in an open space Two-way communication between devices Operating frequencies — 866.0 – 866.6 MHz Self-adjusting RF output power — up to 25 mW Block encryption based on AES algorithm Detector scanning period — 12 – 300 s |
| Operating temperature range | From 0°С to +40°С |
| Permissible humidity | Up to 75% |
| Anti-sabotage | Protection against fraud Jamming detection |
| Protection class of body | IP20 |
| Remote setting and testing | + |
| Dimensions | 65.5 × 45 × 45 mm |
| Weight | 58 g |
| Warranty | Replacement and repair within 24 months of the date of sale. |
