Principle of operation
TThe device controls the security modes and sends an alarm signal to the Central Monitoring Station by pressing the key fob panic button.
Feature
Authentication prevents forgery of the device and false alarm signals.
Connecting and setting up
Ready to operate straight out the box: the battery is already installed, therefore there is no need to disassemble the detector. With one click, it can be connected to the hub in the mobile application.
Tech specs
| Classification | Four-button key fob with command delivery indication |
|---|---|
| Compatibility | Operates with all Ajax hubs, and range extenders, ocBridge Plus, uartBridge |
| False alarm prevention | Yes, long press or double press (firmware version 5.54.1.0 or higher. Manufacture date from March 19, 2020) |
| Number of buttons | 4 |
| Deactivation of the panic button | Available |
| Jeweller radio technology | Communication range with central unit — up to 1,300 m in an open space Two-way communication between devices Operating frequencies — 866.0 – 866.6 MHz Self-adjusting RF output power — up to 20 mW Block encryption based on AES algorithm Device polling period — 12 – 300 s |
| Power supply | Battery: CR2032 battery, 3 V |
| Battery life | Up to 5 years |
| Operating temperature range | From -25°С to +50°С |
| Permissible humidity | Up to 95% |
| Dimensions | 65 × 37 × 10 mm |
| Weight | 13 g |
| Warranty | Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty. |
| Complete set | SpaceControl keyfob CR2032 battery (pre-installed) User’s guide |
