Principle of operation
The device collects information on detector operation in
an encrypted format, analyzes the data, and in case of alarm, notifies the system owner and the
Central Monitoring Station in just milliseconds.
Feature
The device uses Jeweller radio technology to monitor the
detectors and ensure a quick response to danger. It switches the entire system to clear
frequencies during jamming. The device is protected against viruses at software level.
Installation and set up
Ready to operate straight out the box. It is set using
the mobile application, and the detectors are connected with just one click. It can be mounted
in just a few minutes using the SmartBracket mount.
Safe home and office automation
Boost the potential of your security system with
scenarios to actively resist the threats it detects and automate your routines. Set up a Night
mode activation on schedule; turn off all the office lights automatically by arming the system;
program the outdoor lights to spotlight trespassers when they trigger an outdoor motion
detector; or install a sustainable anti-flood system. The system continues to execute scenarios
even if the connection with Ajax Cloud is lost.
Reactions to threats
Planned actions
Reactions to security mode
change
Reactions to threats
Planned actions
Reactions to security mode
change
Tech specs
| Classification | The radio channel central unit with GSM and Ethernet modules |
|---|---|
| Installation | Indoors |
| Connected devices | 100 |
| Users | 50 |
| Rooms | 50 |
| Groups | 9 |
| Mobile apps | iOS 11.0 and later Android 4.4 and later |
| Communication channels | Ethernet, GSM (850/900/1800/1900 MHz) |
| Alarm signal | Delivery time: 0.15 s Types of notifications: SMS message, call, push |
| Communication with Central Monitoring Station | Contact ID, SIA |
| Processor | ARM |
| Operating system | OS Malevich |
| Power supply | 110-250 V from mains or 12 V when using 12V PSU for Hub/Hub Plus/ReX Built-in back-up battery: Li-Ion 2 А·h Up to 15 hours of offline operation when the Ethernet is switched off Energy consumption from the grid — 10 W |
| Jeweller radio technology | Communication range with detectors — up to 2,000 m in an open space Two-way communication between devices Operating frequencies — 866.0 – 866.6 MHz Self-adjusting RF output power — up to 25 mW Block encryption based on AES algorithm Detector polling period — 12−300 s Frequency hopping |
| SIM card support | Micro SIM 2G |
| Operating temperature range | From -10°С to +40°С |
| Anti-sabotage | Protection against fraud Jamming detection Tamper-resistant |
| Video surveillance | Up to 10 cameras or DVRs |
| Remote set up | + |
| Dimensions | 163 × 163 × 36 mm |
| Weight | 350 g |
| Warranty | Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty. |
| Connected ReX | 1 |
| Scenarios | 5. |
| MotionCam detectors support | No |
